Details
Completely reimagined, from the ground up.
The all-new design makes the Altitude even faster than before. With increased stiffness and a lower centre of gravity, overall ride performance is leveled up.
Charge harder. Go faster.
From commanding the clock to holding your own on
weekend rides. This bike is purpose-built to go fast and
demolish steep trails. Its total enduro capabilities can
help you secure that “top step” and tackle demanding
group rides with confidence. With so much capability
in your corner, it’s time to push limits, climb faster, and
charge. Enduro lives at Altitude.
Eats up tough terrain.
Its finely tuned rate curve and concentrated suspension mass let it handle bumps effectively, keeping the rear wheel glued to the ground under power.
It's back!
It was first introduced on the 2006 Slayer, and was
found on later versions of the Slayer SXC and Slayer
SS. The design was then adapted to the popular
2008 Flatline, and then the Flatline WC models. Now,
it's back, and more refined than ever!
Ride support you can count on.
The linear rate curve provides a supportive and predictable feel with minimal unwanted movement or harshness. Mid to large-sized impacts are absorbed effectively without compromising speed or control.
LC2R (Low Centre Counter Rotating) delivers ride
characteristics that balance kinematic variables to
achieve the legendary Rocky Mountain ride feel riders
have come to love. The mixture of a tuned blend
of anti-squat with a rate curve that is efficient and
supportive yet responsive, supple, and quiet provides
maximum traction, comfort and performance.
The RIDE-4 adjustment system allows riders to quickly fine-tune their
geometry with a single Allen key. Four configurations are possible
thanks to one rotating chip on each side. Riders should note that RIDE-4
positions are different on this platform than others.
Our Low Center Counter Rotating (LC2R) suspension aims to provide
maximum traction and comfort in more demanding terrain favoured by
aggressive riders. It features a tuned blend of anti-squat and rate curve
that is efficient and supportive yet supple and quiet. Our co-rotation
suspension design philosophy is centred on ride characteristics that
balances kinematic variables to achieve the legendary Rocky Mountain
ride feel.
FORM tubesets utilize premium materials to meet our strict requirements.
Each FORM tube that we create is engineered for its specific purpose
within the frame, ensuring optimized strength, weight, and ride quality.
Size Specific Tune ensures that riders of all sizes get the right balance
of small-bump compliance, mid-stroke support, and end-stroke
progressiveness. Our design team sets custom shock tunes based on
real world field testing and adjusts each tune for specific frame sizes.
Specs
Frame | FORM™ Alloy | Full Sealed Cartridge Bearings | BSA Threaded BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 160mm Travel |
---|---|
Fork | RockShox Zeb Select RC 170mm | 27.5 = 38mm Offset | 29 = 44mm Offset |
Headset | FSA ZS56|66 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
Rear Shock | Fox Float X Performance | Sealed Bearing Eyelet | 40x10mm F Hardware | SM = 210x55mm | MD – LG – XL = 230x60mm |
Rims/Wheels | WTB ST i30 TCS 2.0 Tubeless | 32H |
Hubs | F: Shimano TC500 | 15x110m | R: Shimano TC500 Boost 148mm |
Spokes | 2.0 Stainless |
Tires | F: Maxxis Minion Assegai 2.5 WT EXO Tubeless Ready | R: Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready |
Crankset | Shimano Deore | 32T | 24mm Spindle | SM = 165mm | MD – XL = 170mm |
Bottom Bracket | Shimano Threaded BBMT501-B |
Chain | Shimano M6100 |
Rear Derailleur | Shimano Deore 12spd |
Cassette/Rear Cogs | Shimano Deore 10-51T 12spd |
Shifters | Shimano Deore 12spd |
Handlebars | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
Tape/Grips | ODI Elite Pro Lock On |
Stem | Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm |
Brakes | Shimano MT6120 4 Piston | Metal Pads Rotors: Shimano RT64 203mm |
Pedals | Not Included |
Saddle | WTB Volt 142 |
Seat Post | X Fusion Manic Composite 30.9mm | SM = 150mm | MD = 170mm | LG – XL = 200mm |
* Subject to change without notice.
Videos
Between Two Wheels - Altitude
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Black / Carbon / Black / Small / 27.5" | 770416533309 | B0331SM2 | ROC39348285K |
Black / Carbon / Black / Medium / 29" | 770416533262 | B0331MD2 | ROC3927121K |
Black / Carbon / Black / Large / 29" | 770416533224 | B0331LG2 | ROC39516120K |
Black / Carbon / Black / X-Large / 29" | 770416533347 | B0331XL2 | ROC39942782K |
